VIRTUS CT2
CITY BIKE
COLOR
BLACK-nardo grey
MOTOR
OLI SPORT PLUS 85NM
BATTERY
36V – 13.4AH – 483WH
MOTOR DATA
Motor 250 Watt torque sensor
Maximun torque 85Nm
Motor weight 3.300 g
Battery 483Wh
Battery weight 3.000 g
Battery range till 150 km
AUTONOMY PERFORMANCE IN KMS OF THE TORQUE DRIVE SYSTEM
DISPLAY SIDE VISION
– screen size: 1.8”
– handlebar bracket: 22.2 mm
– waterproof IP65
– power on/off control
– 5 assistance levels
– battery level
– speed indicator in km/h /mph
– walk assistance 6 km
– headlamp on/off control
– total kilometres /ODO
– partial kilometres / TRIP
– clock
GEOMETRY
COMPONENTS
| TIRES | 26” X 1.75” KETTLER |
| WHEELS | RIMS ALUMINIUM DUOBLE HALL HIGH PROFILE MADE IN ITALY |
| FRAME | HYDROFORMED ALUMINIUM |
| FORK | ZOOM DISC BRAKE VERSION |
| STEM | zoom aluminium ADJUSTABLE |
| HANDLEBAR | ALUMINIUM ITALIA |
| SADDLE | GEL BASSANO |
| SEAT TUBE | ALUMINIUM |
| CHAINWHEEL | ALUMINIUM 170 MM |
| PEDALS | STANDARD |
| BRAKES | HYDRAULIC SHIMANO MT 200 OR TEKTRO HDT 275 - 160 MM DISC |
| GEAR | SHIMANO 7 SPEED REVO SHIFTER |
| DERAILLEUR | SHIMANO 7V TY 300D |
| CASSETTE | shimano freewheel 14-34t |
| DISPLAY | COLOUR LCD 1.8” SIDE VISION OLI |
| MOTOR | OLI SPORT PLUS 85NM |
| MAX SPEED | 25 KM/H |
| BATTERY | LI-ION FRAME SEMI-INTEGRATE 13.4AH 483WH BATTERY USB PORT REMOVABLE |
| BATTERY WEIGHT | 3.1 KG APPROX. |
| CHARGE TIME | 4-5 HOURS |
| MINIMUM CHARGE | 30-40 DAYS |
| AUTONOMY | SEE DATA SHEET |
| WEIGHT | 24 KG |
| REAR CARRIER LOAD CAPACITY | 25 KG |
| MAX CAPACITY | 100 KG |
| FRONT/REAR LIGHT | LED INTEGRATED POWER SUPPLY |
Technical characteristics and components may be subject to changes without prior notice.
