IMAGO TK3
TREKKING
The Imago TK3 e-bike offers a smooth ride in every situation, even on the toughest trails. With its 85 NM of torque, the Oli Sport Plus engine offers the cyclist a stable, precise ride in all conditions.
COLOR
BLACK
MOTOR
OLI SPORT PLUS – 85NM
BATTERY
36V – 17.5AH – 630WH
01
The 630 Wh battery features high-performance cells with an unprecedented range. The battery is fully integrated into the frame for a clean and pared-down design.
02
With its 85 NM of torque, the Oli Sport Plus engine guarantees the right support for cycling on even the toughest trails. With smooth pedalling, it guarantees the rider a stable and precise ride in any conditions.
03
The Oli High Vision display has a sleek, elegant design that gives the rider full control of all engine parameters, such as engine power, cycling cadence and the pedal power of the rider. It also has an automatic brightness adjustment system which can adapt to all riding conditions.
04
The SKS luggage rack is the best choice in terms of quality and design.
The light integrated in the luggage rack also allows you to enjoy your bike even when it’s dark, without sacrificing elegance and clean lines. Ensures high visibility thanks to the LED light.
05
The Suntour fork has been specially designed to guarantee the cyclist a comfortable ride on out-of-town outings, on asphalt, gravel and light dirt roads.
06
The SKS-Germany mudguards are equipped with a quick-release safety system, a technology that allows for fast release of the rods in case foreign bodies enter the wheel, preventing the vehicle from tipping over.
MOTOR DATA
Motor 250 Watt
Maximun Torque 85 Nm
Motor Weight 3.500 Gr
Battery 630 Wh
Battery Weight 3.000 Gr
Battery Range Till 150 Km
AUTONOMY PERFORMANCE IN KMS OF THE TORQUE DRIVE SYSTEM
DISPLAY HIGH VISION
– 2“ screen size
– 31,8mm handlebar bracket
– Light sensor
– Remote control
– Walk mode on the remote control
– BT / ANT+ connectivity
GEOMETRY
| SIZE | RC | WB | BBD | ST | STACK | REACH | TT | HT | FL | FR | SA | HA |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| L | 460 | 1160 | 70 | 490 | 643 | 401 | 597 | 150 | 477 | 42 | 73° | 69° |
| M | 460 | 1113 | 70 | 460 | 643 | 393 | 589 | 150 | 477 | 42 | 73° | 69° |
COMPONENTS
| TIRES | 29 X 2.0” KENDA KHAN K935 |
| WHEELS | RIM PASSION DH 34 MADE IN ITALY |
| FRAME | HYDROFORMED ALUMINIUM |
| FORK | SUNTOUR SR NVX SF 15NVX30TRAVEL 75 |
| STEM | ZOOM STEM EXT 75MM |
| HANDLEBAR | ZOOM TREKKING BARBORE 31.8MM BLACK MATT |
| SADDLE | SELLE ITALIA ST3 SF FEC |
| SEAT TUBE | ZOOM SHOCK ABSORBER SEAT POST SPS-521 EXTENTION 350 |
| CHAINWHEEL | CHAINWHEEL SET 38T |
| PEDALS | NON-SLIP PEDAL |
| BRAKES | HYDRAULIC SHIMANO MT 200 DISCO 160 MM OR ZOOM HB 875 |
| GEAR | shimano shifter sl-m 4100-r |
| DERAILLEUR | shimano sgs rd-m4120/5120 deore |
| CASSETTE | shimano 10v cs-m 4100 11-42 t |
| DISPLAY | MULTIFUNCTION COMPUTER OLI EDS COLOR DISPLAY |
| MOTOR | OLI EDS MOTOR TORQUE SYSTEM 250W SPORT(85NM) |
| MAX SPEED | 25 KM/H |
| BATTERY | 36V 17.5 AH 630 WH REMOVABLE |
| BATTERY WEIGHT | 3,0KG |
| CHARGE TIME | 6-7 HOUR |
| MINIMUM CHARGE | 30-40 DAYS |
| AUTONOMY | SEE DATA SHEET |
| WEIGHT | 26KG |
| REAR CARRIER LOAD CAPACITY | 15KG AND 25KG WITH OPTIONAL SUPPORT BAR |
| MAX CAPACITY | 100KG |
| FRONT/REAR LIGHT | LED INTEGRATED POWER SUPPLY |
Technical characteristics and components may be subject to changes without prior notice.
