AUDAX XC2
FRONT SUSPENDED
Responsive, agile and fast. To ensure excellent rideability in all cycling situations, the steering of the Audax XC2 hardtail has been designed with a 68° angle. Meanwhile the engine plate is made by gravity casting (without welding) which gives a better design and greater strength.
COLOR
GREY-BLACK
MOTOR
OLI SPORT PLUS – 85NM
BATTERY
36V – 20AH – 720WH
01
The 720Wh battery with 21,700 high-performance cells ensures an unprecedented range of up to 260 km. The battery is completely integrated into the frame, which makes for a clean and aerodynamic design.
02
The motor plate is made by gravity casting, a process that avoids welding and allows better design and more precision during assembly while structurally ensuring greater strength. In addition, a dedicated air intake has been included to help cool the Oli Sport Plus motor.
03
The Oli High Vision display has been designed to be slim and elegant, giving the rider full control over all motor parameters, such as: motor power output, pedalling cadence and the rider’s pedalling power. Moreover, it has an automatic brightness adjustment system to adapt to all conditions of use.
04
The steering angle has been designed with a 68° slope to ensure excellent rideability in all pedalling situations. In addition, the extended reach and a short handlebar stem give the rider an optimum riding position: well-centred and balanced.
05
The Suntour XCR34 Boost fork with its 120 mm suspension travel and 34 mm stanchions offers excellent damping capacity even on the roughest terrain, giving the rider a feeling of control and precision also on extremely technical and demanding trails.
06
The Cura brake system offers maximum performance even in the most extreme conditions of use while providing unrivalled braking modulation. Furthermore, the 180 mm brake discs at the front and rear are designed to respond excellently and consistently even in the most demanding conditions.
MOTOR DATA
Motor 250 Watt
Maximun Torque 85 Nm
Motor Weight 3.500 Gr
Battery 720 Wh
Battery Weight 3.490 Gr
Battery Range Till 180 Km
AUTONOMY PERFORMANCE IN KMS OF THE TORQUE DRIVE SYSTEM
DISPLAY HIGH VISION
– 2“ screen size
– 31,8mm handlebar bracket
– Light sensor
– Remote control
– Walk mode on the remote control
– BT / ANT+ connectivity
GEOMETRY
| SIZE | RC | WB | BBD | ST | STACK | REACH | TT | HT | FL | FR | SA | HA |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| L | 465 | 1203 | 60 | 460 | 641 | 452 | 630 | 120 | 526 | 51 | 74,5° | 68° |
| M | 465 | 1177 | 60 | 430 | 637 | 428 | 605 | 115 | 526 | 51 | 74,5° | 68° |
| S | 465 | 1173 | 60 | 410 | 621 | 412 | 585 | 115 | 526 | 51 | 74,5° | 68° |
COMPONENTS
| TIRES | 29" X 2.6" PIRELLI SCORPION ENDURO M O CST PATROL |
| WHEELS | FSA WHSET E-MTB ALLOY GE30 (29") |
| FRAME | HYDROFORMED ALUMINIUM |
| FORK | SUNTOUR XCM AIR BOOST TRAVEL 120MM BLACK STANCHION |
| STEM | ALUMINUM TDS-D600A EXTENTION 50MM |
| HANDLEBAR | ZOOM 320BT MTB W:740MM. X 6° BARBORE 31.8MM. |
| SADDLE | SELLE ITALIA MODEL X BB FEC BOOST |
| SEAT TUBE | ZOOM SP-406 350MM |
| CHAINWHEEL | MICHE CHIANWHEEL 34 TEETH |
| BRAKES | HYDRAULIC BRAKE FORMULA KIT CURA DISCO FRONT. 180MM.REAR. 180MM |
| GEAR | SHIMANO SHIFT LEVER,SL-M6100-R,DEORE,12 SPEED |
| DERAILLEUR | SHIMANO RD-M6100,DEORE,SGS 12 SPEED |
| CASSETTE | sram eagle pg 1210/1230 11-50t 12 V |
| DISPLAY | MULTIFUNCTION COMPUTER OLI EDS COLOR DISPLAY |
| MOTOR | OLI EDS CENTRAL MOTOR TORQUE SYSTEM 250W SPORT (85NM) |
| MAX SPEED | 25 KM/H |
| BATTERY | LI-ION FRAME INTEGRATED 36V 20AH 720WH REMOVABLE |
| BATTERY WEIGHT | 3,490 KG |
| CHARGE TIME | 8/10 HOUR WITH STANDARD CHARGER 4/5 HOUR WITH OPTIONAL CHARGER |
| MINIMUM CHARGE | 30-40 DAYS |
| AUTONOMY | SEE DATA SHEET |
| WEIGHT | 24,9 KG |
| MAX CAPACITY | 100KG |
Technical characteristics and components may be subject to changes without prior notice.
