AUDAX XC1
FRONT SUSPENDED
Challenging and adrenaline pumping descents are no problem: on the Front Suspended Audax XC1 you can go wherever you want. The Polini engine provides great power and fluidity, while the 29” wheels with Pirelli tyres offer an exhilarating riding experience.
The geometry is designed for maximum riding comfort, so on-road and off-road will no longer be an obstacle.
COLOR
BLACK
MOTOR
POLINI E-P3+MX 36V 250W – 90NM
BATTERY
36V – 20AH – 720WH
01
The 720Wh battery with 21,700 high-performance cells ensures an unprecedented range of up to 260 km. The battery is completely integrated into the frame, which makes for a clean and aerodynamic design.
02
The Polini TFT display is an impressive 2.5” in size for easy reading. It has been designed with adaptive light technology that makes colours automatically adjust to changing light conditions. The Polini display provides the rider with all parameters such as pedalling power, cadence and motor.
03
The steering angle has been designed with a 68° slope to ensure excellent rideability in all pedalling situations. In addition, the extended reach and a short handlebar stem give the rider an optimum riding position: well-centred and balanced.
04
The Suntour XCR34 Boost fork with its 120 mm suspension travel and 34 mm stanchions offers excellent damping capacity even on the roughest terrain, giving the rider a feeling of control and precision also on extremely technical and demanding trails.
05
The Cura brake system offers maximum performance even in the most extreme conditions of use while providing unrivalled braking modulation. Furthermore, the 180 mm brake discs at the front and rear are designed to respond excellently and consistently even in the most demanding conditions.
06
The SRAM UDH (Universal Derailleur Hanger) guarantees greater protection for the derailleur gear system, as it can rotate on impact. It facilitates chain alignment and is manufactured to a universal standard, which makes it easy to replace if an accident occurs.
MOTOR DATA
Motor 250 Watt (600W peak)
Maximun torque 90Nm
Motor weight 2.950 g
Battery 720Wh
Battery weight 3.490 g
Battery range till 180 km
Average pedalling frequency 60-80 Rpm
Cyclist weight 60-80 Kg
Range – average speed 20-25 Km/h
Bicycle with road or narrow MTB wheel
Flat terrain
AUTONOMY PERFORMANCE IN KMS OF THE TORQUE DRIVE SYSTEM
POLINI COLOR MULTIFUNCTION COMPUTER
The TFT display is easy to read thanks to the adaptive light 2,5” color screen, with automatic adaptation of the color and intensity according to the ambient light. Furthermore it shows precisely the cyclist pedaling power, the cadence, the motor power and residual range.
GEOMETRY
| SIZE | RC | WB | BBD | ST | STACK | REACH | TT | HT | FL | FR | SA | HA |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| L | 465 | 1203 | 60 | 460 | 641 | 452 | 630 | 120 | 526 | 51 | 74,5° | 68° |
| M | 465 | 1177 | 60 | 430 | 637 | 428 | 605 | 115 | 526 | 51 | 74,5° | 68° |
| S | 465 | 1152 | 60 | 410 | 632 | 404 | 580 | 110 | 526 | 51 | 74,5° | 68° |
COMPONENTS
| TIRES | 29” X 2.6” PIRELLI SCORPION ENDURO M |
| WHEELS | MICHE XM-H 30 AXY (29”) |
| FRAME | HYDROFORMED ALUMINIUM |
| FORK | SUNTOUR SR XCR34 AIR BOOST TRAVEL 120 MM BLACK STANCHION |
| STEM | ALUMINUM BARBORE 35 EXT 35 MM |
| HANDLEBAR | MTB ZOOM 320BTW: 740 MM 6° BARBORE 31.8 MM |
| SADDLE | SELLE ITALIA MODEL X BB FEC BOOST |
| SEAT TUBE | ZOOM SP-406 350 MM |
| CHAINWHEEL | MICHE CHAINWHEEL 34 TEETH |
| BRAKES | HYDRAULIC BRAKE FORMULA KIT CURA DISC FRONT 180 MM REAR 180 MM |
| GEAR | SHIMANO SHIFT LEVER, SL-M6100-R, DEORE, 12 SPEED |
| DERAILLEUR | SHIMANO RD-M6100, DEORE, SGS 12 SPEED |
| CASSETTE | CASSETTE M600 BLACK 12 SPEED 11-50T |
| DISPLAY | MULTIFUNCTION COMPUTER POLINI COLOR DISPLAY |
| MOTOR | POLINI E-P3+MX 36V 250W 90NM |
| MAX SPEED | 25 KM/H |
| BATTERY | LI-ION FRAME INTEGRATE 36V 20AH 720WH REMOVABLE |
| BATTERY WEIGHT | 3,490 KG |
| CHARGE TIME | 7/8 HOURS WITH STANDARD CHARGER 4/5 HOURS WITH OPTIONAL CHARGER |
| MINIMUM CHARGE | 30-40 DAYS |
| AUTONOMY | SEE DATA SHEET |
| WEIGHT | 23.7 KG |
| MAX CAPACITY | 100 KG |
Technical characteristics and components may be subject to changes without prior notice.
